Agricultural Implement Tires

Min.Order: 10 Pcs
JABIL Agricultural Implement Tires provide exceptional load - bearing capabilities. These tires are designed to carry the heavy weights of agricultural implements, such as plows, seed drills, and trailers filled with harvested crops. Reinforced internal structures and robust sidewalls ensure that the tires can withstand the immense pressure and stress exerted by these loads without deforming or failing.

Send Inquiry

Product Description

Additionally, Agricultural Implement Tires feature deep and rugged tread patterns that offer superior traction on different terrains, from muddy fields to dry, compacted soil. The tires also have excellent shock - absorbing properties, which help to protect the delicate components of the agricultural implements from damage caused by uneven ground surfaces.

JABIL Agricultural Implement Tires,used for implements transportation operation,suitable for soft ground,mud and sand agricultural operations,with excellent traction and efficient self-cleaning capability.

Product Parameter(Specification)

Pattern	Size	Ply	Overall Diameter (mm)	Section WidHS (mm)	Rim	Load Capacity (Kg)	Inflated Pressure (Kpa)	Type
F2	4.00-12	6	535	110	3.00D	250	340	TT
F2	4.00-14	6	590	110	3.00D	315	450	TT
F2	5.00-15	6	665	140	4J	465	420	TT
F2	5.50-16	6	710	150	4.00E	525	370	TT
F2	6.00-16	8	740	160	4.00E	675	450	TT
HS657	5.50-16	6	670	110	4.00E	1350	530	TT
HS657	6.00-16	8	680	120	4.50E	850	530	TT
F2	6.50-16	8	760	175	4.50E	735	420	TT
F2	6.50-20	10	860	180	5.00F	865	420	TT
F2	750-16	8	810	205	5.50F	870	370	TT/TL
F2	750-18	8	860	205	5.50F	945	370	TL
F2	9.00-16	8	860	235	6LB	1080	310	TL
F2	10-15	8	855	276	8LB	1425	240	TT
F2(3RIB/4RIB)	10.00-16	10	910	275	W8L	1325	340	TL
F2(3RIB/4RIB)	11.00-16	10	970	315	W10L	1485	310	TL
I1	11L-15	12	775	280	8LB	1130	220	TL
I1	750-16	12	785	203	5.50F	1240	400	TL
IMP100	700-12	12	683	192	5.00F	1050	390	TL
IMP100	10.0/80-12	8	710	264	9	1250	390	TL
IMP100	10.0/75-15.3	10	760	264	9	1525	390	TL
IMP100	11.5/80-15.3	12	865	290	9	2145	410	TL
IMP100	12.5/80-15.3	14	875	307	9	2810	510	TL
C2	12.00-18	12	1100	340	9.00V	1950	420	TL
PR-1	600-12	6	690	165	5.00F	425	270	TT
PR-1	600-14	6	710	165	4.50E	530	330	TT
PR-1	650-16	8	830	165	5.00F	565	250	TT
PR-1	750-16	8	890	195	5.50F	750	300	TT
PR-1	8.3-20	8	950	210	W7	970	270	TT
PR-1	8.3-24	8	1050	210	W7	1135	270	TT

Product Feature and Application

Product Feature

✔

Exceptional traction and efficient self-cleaning performance;

✔

High strength, good load-bearing capacity, excellent wear resistance, and good puncture resistance.

Application

Farmland operations and short-distance transportation
